تفاصيل المنتج:
|
| Function: | compression test,Paper Tube Compressive Strength Test,Burst tester,tensile test,Paper Testing Instrument | Name: | paper cup tube compressive strength tester,Paper testing instrument paper gsm tester/ bursting strength tester,paper testing instrument |
|---|---|---|---|
| Display: | LCD,Digital display | Feature: | easy to operate |
| Operation Method: | Automatic | Product Type: | Testing Instruments |
| Protection Device: | Induction type protection device | Control: | PLC control |
| Sensing Method: | Pressure Transmitter | Stop: | Stop test |
| Force Resolution: | 1/500000 of the maximum test force fs | Vibration Mode: | reciprocating |
| إبراز: | Absorption Sanitary Tampon Tester,High Precision Sanitary Tampon Tester,PLC Control Sanitary Tampon Tester,High Precision Sanitary Tampon Tester,PLC Control Sanitary Tampon Tester |
||
| Feature | Specification |
|---|---|
| Water Bath Capacity | 6 L |
| Testing Stations | 5 stations |
| Water Bath Temperature Range | -5°C to 100°C (±0.5°C accuracy) |
| Internal Circulation Pump Flow Rate | 50 ± 2ml/h |
| External Circulation Pump Flow Rate | 0-24000ml/h (adjustable) |
| Pumping Pipe Dimensions | 6.4mm ID × 9.6mm OD |
| Needle Size | 100mm length, 1.5mm ID, 1.8mm OD |
| Triangular Beakers | 5 pieces included |
| Power Requirements | 220V, 50Hz, 1kW |
| Dimensions (L×W×H) | 800 × 500 × 1200mm |
| Weight | 60kg |
| Attribute | Value |
|---|---|
| Function | Compression test, Paper Tube Compressive Strength Test, Burst tester, Tensile test, Paper Testing Instrument |
| Display | LCD, Digital display |
| Operation Method | Automatic |
| Product Type | Testing Instruments |
| Control System | PLC control |
| Sensing Method | Pressure Transmitter |
| Force Resolution | 1/500000 of the maximum test force FS |
| Vibration Mode | Reciprocating |
